Horse Barn Plans from Louisiana State University's AgCenter

Twelve Free Horse Barn Plans from the Ag Center at Louisiana State University

Download free design plans and building details for any of twelve different horse barns with from one to seventeen stalls.





These free, instant download plans and building details for a

dozen different horse barns and stables include designs for from one to seventeen stalls, in a variety of styles.



Horse Barn 26' X 48' (Gambrel Roof)
Building plans for a three-stall horse barn with a work area, feed and tack rooms.

 Horse Barn (Post Construction)
Building plans for a 36' X 24' three-stall horse barn.

 Horse Barn (Gambrel Roof)
Detailed plans to build a 16' X 24' horse barn with either tie or box stalls and storage on the second floor under a gambrel roof.

 Horse Barn (Plywood)
Plans for a two-stall horse barn with a feed and tack room built with plywood siding.

 Horse Barn (Pole Construction)
Construction plans for a 24' X 30' pole construction horse barn with three stalls, work area, feed and tack rooms.

 Portable Stable for One Horse
Building plans for an enclosed wooden frame one-horse stable on skids.

 1-1/2 Story Horse Barn
Building plans for a gambrel roof, three-stall horse barn (48' X 24') with feed and tack rooms and a hay loft.

 Saddle Horse Barn
Construction plans for four-stall pole horse barn with a room for feed and tack.

 Horse Barn - 17 Stall
Building plans for a 100' X 36' enclosed wood frame 17-stall horse barn with tack and feed rooms.

 2 Stall Riding Horse Barn
Construction plans for a two-stall barn with feed and tack rooms.

 Horse Barn (Gambrel)
Building plans for a two-story, gambrel roof, wooden frame barn for horses with six stalls, feed, hay and tack rooms.

 Horse Barn for Hot, Humid Climate
Building plans for two small horse barns designed with Louisiana's hot and humid climate in mind.



About These Cooperative Extension Plans:  These plans were developed over many years by engineers at LSU and other U.S. Land Grant universities. They are generally older plans that need to be revised for today's construction methods, codes and standards. They provide design ideas and conceptual information for planning purposes. The plans were prepared through the US Department of Agriculture Cooperative Farm Buildings Plan Exchange.

Buildings must resist various forces from snow, wind, earthquake and use. They also must adhere to local building and zoning codes. A local building inspector, engineer, building supplier, or building contractor can help you determine what is a safe and legal building for your area.

Visit LSUAgCenter.com for additional information.
